DESCRIPTION
| Product specification | |||
| Project | M99 | Updated：2025/05/17 | Version：A0 |
| Item | Feature | Specification description | Remark |
| ID | Size: | Length48mm *Width47mm* Thickness13.8mm | |
| ID |  | ||
| Color | Gunmetal/Gold | ||
| Key Component | Main Chip | SL8541E | |
| Display | 2.16/inches AMOLED 480*480 | 24pin BTB | |
| Touch Panel | 2.16/inches oncell 480*480 | COF | |
| DDR3RAM | 3GB | ||
| FlashROM | 32GB | ||
| Battery | 1100mA/h | Three Wire Soldering, Protection Board Seiko 3.0V Protection – with NTC | |
| Loudspeaker | 1507 Solder wire type | ||
| Motor | 0820 Welding Wire Motor | ||
| Microphone | YES | 4015 Solder wire type | |
| Port | TF SD soket | No TF card slot | |
| SIM soket | cartouche | nano | |
| Charge Port | pogo PIN | ||
| USB Jack | NO | ||
| Indicator light | NO | ||
| Camera | Front | 2 million | SP0A09 Pull-out Swivel Camera |
| Rear | |||
| Data | Wifi | With wifi Single band 2.4Ghz | LDS |
| 2G | (B2.B3.B5.B8) | Overseas version (global frequency band), specific individual countries can send samples for testing | |
| 3G | (B1.B2.B5.B8) | ||
| 4G | (FDD.B1.B2.B3.B4(66).B5.B7.B8.B12.B17.B20.B28F), (TDD.B3.B4.B38.B39.B40.B41) | ||
| Bluetooth | Support for V4.2 | Same as wifi 3-in-1 LDS antenna | |
| GPS | Support forGPS | ||
| NFC | Supported, writable to normal access control | ||
| menu bar | Phone, Messages, Settings, Camera, Albums, Music, Sports, Piay Store, TikTok, Browser, Free Watch UI Change, App Market, Video Player, Heart Rate, Blood Pressure, Blood Oxygen, Walking, Sleep Detection, Contacts, Voice Recorder, Calendar, Calculator, Clock, Stopwatch, One Tap Cleanup, One Tap Drain, Super Power Saver, Style Settings, NFC, File Browser, Maps. Bluetooth assistant (supports Bluetooth calls when connected) | ||
| Sensor | Gravitysensor | Support for | SC7A22C/H |
| Gyroscope | NO | ||
| Heart rate sensor | BD1820 | ||
| Hall switch | NO | ||
| The temperature | NO | ||
| Physical buttons | Power key | YES | |
| function key | YES | ||
| The machine power consumption | Standby time | N/A：Standby without card for 3 days | |
| Normal service time | N/A：Plug in the card for 1-2 days of normal use | ||
| Call | Phone | Support (VOLTE is required to use China Telecom operators) | |
| Software | OS | Adriod8.1 | |
| UI | Dial Customization | ||
| Language | multilingual | ||
| bracelet | Private Strap | ||
| Watch color | Gunmetal/Gold | ||
| Net weight (watch) | 67g | ||
| Gross weight (packaging) | 253g | ||
| Watch size | Length48mm *Width47mm*Thickness13.8mm | ||
| Package size | 171*88*50mm | ||
| Carton Size | Length 380mm Width 270mm Height 360mm | ||
| Quantity per box | 40 units | ||
| Gross Weight | 12.5KG | ||
| Packaging content | SmartWatch | ||
